Operator's Guide 15
BASIC CONNECTIONS
POWER RECEPTACLE
The power receptacle is located at the left-rear corner of the printer, below
the power on/off switch.
DA0-H
One end of the power cord plugs into
the lower portion of the receptacle.
The other end of the power cord plugs
into a standard three-prong, grounded
electrical outlet. Plug power cord only
into the type of power source
specified in the window near the top of
the receptacle. The window shows
either 120 Vãc, 100 Vãc, 220 Vãc, or
240 Vãc.
The compartment above the power
cord contains a voltage selection
tumbler and two fuses. If necessary,
to change the voltage selection or the
fuses, refer to "Changing Fuses,"
Page 107.
