EPSON Stylus Pro 4400/4450/4800/4880/4880C Revision C
Disassembly & Assembly Disassembly Procedures 224
4.2.3.8 P Cover Open Sensor
1. Remove "Panel, Front/Panel Unit" (p219).
2. Release the two tabs securing "P Cover Open Sensor" and then release
the "P Cover Open Sensor".
3. Disconnect the connector from the "P Cover Open Sensor".
Figure 4-26. P Cover Open Sensor Removal
Tabs
P Cover Open Sensor
Connector
