EPSON Stylus Pro 4400/4450/4800/4880/4880C Revision C
Disassembly & Assembly Disassembly Procedures 365
4.2.11.2 Cover, Front, Right 4 Color (4-color Model)
1. Remove "Panel, Front/Panel Unit" (p219).
2. Remove the four screws that secure the "Cover, Front, Right 4
Color", and remove the "Cover, Front, Right 4 Color".
 C.B.S. 3x6: 4pcs.
Figure 4-234. Cover, Front, Right 4 Color Removal
 When installing the the "Cover, Front, Right 4 Color",
tighten the screws in the order shown in Figure 4-234
 Match the four dowels with the four positioning holes.
1
2
3
4
Dowels and Positioning Holes
