Epson Stylus Pro 4450 - ASF Paper Sensor Removal

EPSON Stylus Pro 4400/4450/4800/4880/4880C Revision C
Disassembly & Assembly Disassembly Procedures 265
4.2.6.5 ASF Paper Sensor
1. Remove PCB Unit. (Refer to "4.2.4.1 C593 MAIN Board" (p226).)
2. Release "ASF Paper Sensor" harness from clamp.
3. Release the two tabs securing "ASF Paper Sensor" and then release "ASF
Paper Sensor".
4. Disconnect connector from "ASF Paper Sensor".
Figure 4-76. ASF Paper Sensor Removal
Clamp
Harness
ASF Paper Sensor
Connector
