CONFIDENTIAL
Paper roll Bit-image commands ESC *
Ver. 10.01 p. 203
TM-L90
The modes selectable by
m
are as follows:
“Vertical” is in the direction of paper feeding and “horizontal” is perpendicular (at right angles)
to the direction of paper feeding.
See Function 5 of GS ( E for specifying the paper width.
See Functions 49 and 50 of GS ( E for specifying the origin of layout (paper layout is not used / top
of a black mark / bottom of a label).
When both standard mode and page mode are selected (a starting position specified by ESC T is
upper left or lower right).
A horizontal maximum print area is decided according to the width of the paper.
When paper layout is not used or top of black mark is selected.
When paper layout is selected as the bottom of label.
m
Mode
Vertical dot
density
Horizontal
Dot density Set adjacent dots
Maximum number of dots
Paper layout is not used /
Top of a black mark Bottom of a label
0 8-dot single-density 203/3 dpi 203/2 dpi Permitted 128 to 288 112 to 280
1 8-dot double-density 203/3 dpi 203 dpi Permitted 256 to 576 224 to 560
32 24-dot single-density 203 dpi 203/2 dpi Permitted 128 to 288 112 to 280
33 24-dot double-density 203 dpi 203 dpi Permitted 256 to 576 224 to 560
Paper width Single density mode (
m
= 0, 32) Double density mode (
m
= 1, 33)
80 mm to 78 mm 288 dots 576 dots
77 mm to 38 mm (256 + (paper width – 38) × 8 / 2) dots (256 + (paper width – 38) × 8) dots
Paper width Single density mode (
m
= 0, 32) Double density mode (
m
= 1,33)
80 mm 280 dots 560 dots
79 mm to 38 mm (224 + (paper width – 38) × 8 / 2) dots (224 + (paper width – 38) × 8) dots
