Epson TM-T88III

CONFIDENTIAL
Paper roll Customize commands GS ( E
Ver. 10.01 p. 604
GS ( E pL pH fn y c1 c2[x d1...d(y × x)] k <Function 8>
[Name] Define the data (column format) for the character code page
[Format] ASCII GS ( E pL pH fn y c1 c2 [x d1...d(y × x)]k
Hex 1D 28 45 pL pH 08 y c1 c2 [x d1...d(y × x)]k
Decimal 294069 pL pH 8 y c1 c2 [x d1...d(y × x)]k
[Range] 5 ≤ ( pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
fn = 8
128 ≤ c1 ≤ d2 ≤ 255
0 ≤ d ≤ 255
k = c2 – c1 + 1
[Description] Defines the character pattern (column format) for the character code page in the work area.
• y specifies the number of bytes in the vertical direction.
• c1 specifies the beginning character code for the definition, and c2 specifies the final code.
• x specifies the number of dots in the horizontal direction from the left.
• d specifies the defined data (column format).
• k indicates the number of the defined data. k is an explanation parameter; therefore, it does not need
to be transmitted.
[Notes]
■ This function works in user setting mode.
■ Characters 80H to FFH in ASCII code can be defined.
■ If
y, c1, c2, or x process a value out of the definition range, processing of this function is canceled.
Font No. (configuration)
yx
10 (9 ×17) 3 9
12 (12 × 24) 3 12
17 (8 × 16) 2 8
18 (10 × 24) 3 10
