Paper roll Bit-image commands GS ( L GS 8 L
Ver. 10.01 p. 237
GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b <Function 67 >
GS 8 L p1 p2 p3 p4 m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
[Name] Define the NV graphics data (raster format).
[Format] ASCII GS ( L
pL pH m fn a kc1 kc2 b
xL
xH
yL
yH [c d1...dk]1...[c d1...dk]b
Hex 1D 28 4C
pL pH
30 43 30
kc1 kc2 b
xL
xH
yL
yH [c d1...dk]1...[c d1...dk]b
Decimal 294076
pL pH
48 67 48
kc1 kc2 b
xL
xH
yL
yH [c d1...dk]1...[c d1...dk]b
ASCII GS 8 L
p1 p2 p3 p4 m fn akc1
kc2
b
xL
xH
yL
yH
[c d1...dk]1...[c d1...dk]b
Hex 1D 38 4C
p1 p2 p3 p4
30 43 30
kc1
kc2
b
xL
xH
yL
yH
[c d1...dk]1...[c d1...dk]b
Decimal 295676
p1 p2 p3 p4
48 67 48
kc1
kc2
b
xL
xH
yL
yH
[c d1...dk]1...[c d1...dk]b
[Range] 12 ≤ (
pL
+
pH
× 256) ≤ 65535
(0 ≤
pL
≤ 255, 0 ≤
pH
≤ 255)
[When using GS 8 L: 12 ≤ (
p1
+
p2
× 256 +
p3
× 65536 +
p4
× 16777216) ≤ 4718604]
m
= 48,
fn
= 67,
a
= 48
32 ≤
kc1
≤ 126
32 ≤
kc2
≤ 126
b
= 1, 2
1 ≤ (
xL
+
xH
× 256) ≤ 8192 (0 ≤
xL
≤ 255, 0 ≤
xH
≤ 32)
1 ≤ (
yL
+
yH
× 256) ≤ 2304 (0 ≤
yL
≤ 255, 0 ≤
yH
≤ 9)
c
= 49, 50 (when the recommended two-color paper is used)
c
= 49 (when the recommended monochrome paper is used)
0 ≤
d
≤ 255
k
= (int((
xL
+
xH
× 256) + 7)/8) × (
yL
+
yH
× 256)
TM-J2000/J2100:
b
= 1, 2 (TM-J2100 [two-color printing model]: when c = 49, 50)
b
= 1 (TM-J2100 [two-color printing model]: when c = 51 or
TM-J2000 [single-color printing model])
1 ≤ (
xL
+
xH
× 256) ≤ 8192 (0 ≤
xL
≤ 255, 0 ≤
xH
≤ 32)
1 ≤ (
yL
+
yH
× 256) ≤ 2304 (0 ≤
yL
≤ 255, 0 ≤
yH
≤ 9)
49 ≤
c
≤ 51 (TM-J2100 [two-color printing model])
c
= 49 (TM-J2000 [single-color printing model])
