Paper roll Miscellaneous commands GS ( K
Ver. 10.01 p. 441
GS ( K <Function 48>
[Name] Select the print control mode
[Format] ASCII GS ( K pL pH fn m
Hex 1D 28 4B 02 00 30 m
Decimal 2949752 0 48 m
[Range] TM-J2000/J2100:( pL + pH × 256) = 2 ( pL = 2, pH = 0)
fn = 48
1 ≤ m ≤ 3, 49 ≤ m ≤ 51
TM-T90:1 ≤ m ≤ 4, 49 ≤ m ≤ 52
TM-L90:0 ≤ m ≤ 4, 48 ≤ m ≤ 52
TM-P60: m = 49, 50
[Default] TM-J2000/J2100: m = 2
TM-T90, TM-L90: m = 1
TM-P60: m = 49
[Description] Selects the print control mode by m .
• The specification of each print control mode differs, depending on the printer model. See model-
dependent variations.
[Notes]
None.
[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-L90, TM-P60
m Function
0, 48 Print mode when power is turned on
1, 49 Print control mode 1
2, 50 Print control mode 2
3, 51 Print control mode 3
4, 52 Print control mode 4
