Epson TM-T88III Programming Guide

CONFIDENTIAL
Paper roll Bit-image commands FS q
Ver. 10.01 p. 275
FS q
EXECUTING + SETTING
[Name] Define NV bit image
[Format] ASCII FS q n[xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
Hex 1C 71 n[xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
Decimal 28 113 n[xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n
[Printers not featuring this command] TM-L90, TM-L60II, TM-P60, TM-U230, TM-U210, TM-U300A/B
[Range] TM-J2000/J2100:1 ≤ n ≤ 255
1 ≤ ( xL + xH × 256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ ( yL + yH × 256)≤ 576 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 2)
0 ≤ d ≤ 255
k = ( xL + xH × 256) × ( yL + yH × 256) × 8
Total defined data area is maximum 384 KB
TM-T90:1 ≤ n ≤ 255
1 ≤ ( xL + xH × 256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ (y L + y H × 256) ≤ 288 (0 ≤ y L ≤ 255, y H = 0, 1)
0 ≤ d ≤ 255
k = ( xL + xH × 256) × ( yL + yH × 256) × 8
Total defined data area is maximum 384 KB
TM-T88III:1 ≤ n ≤ 255
1 ≤ ( xL + xH × 256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ ( yL + yH × 256) ≤ 288 (0 ≤ yL ≤ 255, yH = 0, 1)
0 ≤ d ≤ 255
k = ( xL + xH × 256) × ( yL + yH × 256) × 8
Total defined data area is 256 KB
TM-U220:1 ≤ n ≤ 255
1 ≤ ( xL + xH × 256) ≤ 1023 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 3)
1 ≤ ( yL + yH × 256) ≤ 288 (0 ≤ yL ≤ 255, yH = 0, 1)
0 ≤ d ≤ 255
k = ( xL + xH × 256) × ( yL + yH × 256) × 8
Total defined data area is 128 KB
Bit-image commands
obsolete command
obsolete command
