CONFIDENTIAL
Paper roll Customize commands GS ( E
Ver. 10.01 p. 597
GS ( E pL pH fn a <Function 6>
[Name] Transmit the customized setting values
[Format] ASCII GS ( E
pL
pH
fn
a
Hex 1D 28 45
02 00 06 a
Decimal 294069
2 0 6 a
[Range] (
pL
+
pH
× 256) = 2 (
pL
= 2,
pH
= 0)
fn
= 6
TM-U220, TM-J2000/J2100:
a
= 3
TM-T90:
a
= 1, 2, 3, 5, 6, 97, 116, 118 [Other than Japanese model]
a
= 1, 2, 3, 5, 6, 97, 116 [Japanese model]
TM-L90:
a
= 1, 2, 5, 6, 97, 116, 117, 118
TM-P60:
a
= 3, 5, 116
[Description] Transmits the customized value specified by
a
.
[Notes]
■ This function works both in user setting mode and during normal printer operation.
a
Type of customized value
1 NV user memory capacity
2 NV graphics memory capacity
3 Paper width
5 Print density
6 Print speed
97 Number of division of thermal head energizing
116, 117, 118 Value differs, depending on the printer model. See Function 5.
To Next Page
