Epson TM-T88III Programming Guide

CONFIDENTIAL
Paper roll Two-dimension code commands GS ( k
Ver. 10.01 p. 523
GS ( k <Function 080>
[Name] PDF417: Store the data in the symbol storage area
[Format] ASCII GS ( k pL pH cn fn m d1...dk
Hex 1D 28 6B pL pH 30 50 30 d1...dk
Decimal 2940107 pL pH 48 80 48 d1...dk
[Range] 4 ≤ ( pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
cn = 48
fn = 80
m = 48
0 ≤ d ≤ 255
k = ( pL + pH × 256) – 3
[Description] Stores the PDF417 symbol data ( d1...dk ) in the symbol storage area.
[Notes]
■ Data stored in the symbol storage area by this function are processed by Function 081 and 082. The data in
the symbol storage area are reserved after processing Function 081 or 082.
■ k bytes of d1...dk are processed as symbol data.
■ Specify only the data codeword of the symbol with this function. Be sure not to include the following data
in the data d1...dk because they are added automatically by the printer.
• Start pattern and stop pattern
• Indicator codeword of left and right
• The descriptor of symbol length (the first codeword in the data area)
• The error correction codeword calculated by modulus 929
■ Settings of this function are effective until the following processing is performed:
• Function 080 or 180 or 280 is executed
• ESC @ is executed
• The printer is reset or the power is turned off
