Paper roll Miscellaneous commands DLE DC4 (fn = 1)
Ver. 10.01 p. 383
DLE DC4 (fn = 1)
EXECUTING COMMAND
[Name] Generate pulse in real-time
[Format] ASCII DLE DC4
nmt
Hex 10 14
nmt
Decimal 16 20
nmt
[Printers not featuring this command] TM-L60II, TM-P60, TM-U210, TM-U230, TM-U300A/B
[Range]
n
= 1
m
= 0, 1
1 ≤
t
≤ 8
[Description] Outputs the pulse specified by
t
to connector pin
m
as follows in real time:
The pulse ON time is [
t
× 100 ms] and the OFF time is [
t
× 100 ms]
[Notes]
■ This is a real-time command that the printer executes upon receiving it. Note the following when using
this command.
• If this command is embedded within the code string of another command, it is processed as a
parameter of the other command, and the print result is not correct.
• If another command (such as graphics data or defined data) has a code string in a parameter that is the
same as this command, the printer starts processing this command.
■ This command is ignored in the following states:
• In error status
• When the pulse is being output to the connector pin (during processing of ESC p and DLE DC4)
• During transmission of block data (Header ~ NUL)
• When this command is disabled by GS (D
m
Connector pin
0 Drawer kick-out connector pin 2
1 Drawer kick-out connector pin 5
Miscellaneous commands
