Paper roll Bit-image commands GS ( L GS 8 L
Ver. 10.01 p. 272
GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk <Function 113>
GS 8 L p1 p2 p3 p4 m fn a bx by c xL xH yL yH d1...dk
[Name] Store the graphics data in the print buffer (column format).
[Format] ASCII GS ( L pL pH mfna bx by c xL xH yL yH d1...dk
Hex 1D 28 4C pL pH 30 71 30 bx by c xL xH yL yH d1...dk
Decimal 294076 pL pH 48 113 48 bx by c xL xH yL yH d1...dk
ASCII GS 8 L p1 p2 p3 p4 m fn abx by c xL xH yL yH d1...dk
Hex 1D 38 4C p1 p2 p3 p4 30 71 30 bx by c xL xH yL yH d1...dk
Decimal 295676 p1 p2 p3 p4 48 113 48 bx by c xL xH yL yH d1...dk
[Range] 12 ≤ ( pL + pH × 256) ≤ 32778 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 128)
[When using GS 8 L: 12 ≤ ( p1 + p2 × 256 + p3 × 65536 + p4 × 16777216) ≤ 32778]
m = 48, fn = 113, a = 48
0 ≤ d ≤ 255
k = ( xL + xH × 256) × (int(( yL + yH × 256) + 7)/8)
TM-J2000/J2100:49 ≤ c ≤ 51 (TM-J2100 [two-color printing model])
c = 49 (TM-J2000 [single-color printing model])
1 ≤ ( xL + xH × 256) ≤ 2048 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 8)
1 ≤ ( yL + yH × 256) ≤ 128 (1 ≤ yL ≤ 128, yH = 0)
[Description] Stores the graphics data (column format) in the print buffer.
• Users have the option of specifying horizontal bx × vertical by size settings for the selected data.
• c specifies the color of the stored data.
• xL and xH specify the number of dots in the horizontal direction as ( xL + xH × 256).
c Color specifications
49 Color 1
50 Color 2
51 Color 3
