CONFIDENTIAL
Paper roll Bit-image commands GS /
Ver. 10.01 p. 287
TM-T88III
This command can be used in standard mode only.
The dot density and the maximum print area are described in the next tables (dpi: number of dots
per 25.4 mm).
“Vertical” is in the direction of paper feeding and “horizontal” is perpendicular to the direction of
paper feeding.
The maximum print area in the vertical direction is information used when graphics are printed
with the page mode selected (for the starting position specified with ESC T is “Upper right” or
“Lower left”). In this case, bit images rotated by 90 degrees or 270 degrees are printed
TM-L60II
The dot density and the maximum print area are described in the next tables (dpi: number of dots
per 25.4 mm).
“Vertical” is in the direction of paper feeding and “horizontal” is perpendicular (at right angles)
to the direction of paper feeding.
The maximum print area in the vertical direction is information used when graphics are printed
with the page mode selected (for the starting position specified with ESC T is “Upper right” or
“Lower left”). In this case, bit images rotated by 90 degrees or 270 degrees are printed.
Scaling
Vertical Horizontal
Dot density Maximum print area (dot) Dot density
Maximum print area (dot)
Paper width 80 mm Paper width 58 mm
×
1 180 dpi 831 180 dpi 512 360
×
2 90dpi 415 90 dpi 256 180
Scaling
Vertical Horizontal
Dot density
Maximum print area (dot)
Dot density Maximum print area (dot)Thermal label paper Thermal roll paper
×
1 180 dpi 368 384 180 dpi 831
×
2 90dpi 184 192 90 dpi 415
