CONFIDENTIAL
Paper roll Status commands GS j
Ver. 10.01 p. 328
■ (*1) Status A is shown in the table below:
■ (*2) Status B is shown in the table below:
Bit Function Binary Hexadecimal Decimal
0 Ink end not detected (1st color) 0 00 0
Ink end detected (1st color) 1 01 1
1 Ink end not detected (1st color) 0 00 0
Ink end detected (1st color) 1 02 2
2 Ink cartridge installed (1st color) 0 00 0
Ink cartridge not installed (1st color) 0 04 4
3 Ink cartridge installed (2nd color) 0 00 0
Ink cartridge not installed (2nd color) 1 08 8
4 Reserved - - -
5 Cleaning is not being performed 0 00 0
Cleaning is being performed 1 20 32
6Fixed 1 40 64
7Fixed 0 00 0
Bit Function Binary Hexadecimal Decimal
0 Ink near-end not detected (2nd color) 0 00 0
Ink near-end detected (2nd color) 1 01 1
1 Ink end not detected (2nd color) 0 00 0
Ink end detected (2nd color) 1 02 2
2 ~ 5 Reserved - - -
6Fixed 1 40 64
7Fixed 0 00 0
