CONFIDENTIAL
Paper roll Miscellaneous commands GS ( A
Ver. 10.01 p. 419
■ For the label paper or black paper control, it calculates the effect value used for the actual print operation
based on the paper layout set value, the paper width set value, or the limitation value of the mechanical
structure (mechanical pitch or position of the print head, and so on). The set value and effect value can be
acquired by Function 50 of GS ( E.
[Model-dependent variations] TM-L90, TM-U210
TM-L90
When processing for automatic setting of paper layout (
m
= 64), the printer recognizes origin of
layout on current paper as the setting value, and other setting values are read from measuring or
fixed values. After executing this command, the setting values of paper layout can be confirmed
by GS ( E <Function 50>.
• The letters in parentheses () indicate the parameter of GS ( E <Function 49>.
When origin of layout (
sa
) is “None (paper layout is not used)”:
When origin of layout (
sa
) is “Top of a black mark” (BM = black mark):
Program Example
PRINT #1, CHR$(&H1D);”(A”;CHR$(1);CHR$(2);
Parameter of Paper layout Setting value
The layout of the vertical direction (
sb
) ~ (
sf
)None
The layout of the horizontal direction (
sg
), (
sh
)None
Parameter of Paper layout Setting value
Top of a BM ~ top of next BM (
sb
) Measured value
Top of a BM ~ bottom of BM (
sc
) Measured value
Other than the layout of the vertical direction (
sd
)
~ (
sf
)
Fixed value
The layout of the horizontal direction (
sg
), (
sh
) Fixed value
