Paper roll Customize commands GS ( E
Ver. 10.01 p. 601
■ User defined code pages are page 255 or page 254 in the character code pages of alphanumeric Katakana
characters built in the printer. Character data defined in the user-defined code page can be printed by
specifying the character code after selecting the page with ESC t.
■ Work area means RAM area that is used to edit character data.
■ Storage area means non-volatile memory area that is used to store page data of user-defined code pages.
■ Character data can be specified as follows:
• Character data can be changed in the work area.
• Rewrites the data in the user-defined code page (storage area) by executing Function 4.
• Function 2 should be executed before defining character data, and Function should be executed after
defining character data.
• Specify the same font number in processing Function 2 and Function 4.
[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-L90, TM-P60, TM-U220
TM-J2000/J2100
The relation between the font number and code page is as follows:
<Other than Japanese models>
Procedure Processing Used function
1 Shifts to the user setting mode Function 1
2 Copy data from storage area into work area Function 7 (
d1
= 31,
d2
= 30)
3 Change pattern of the character data Function 8 or Function 9
4 Copy data from work area into storage area Function 7 (
1
= 30,
d2
= 31)
5 Exit user setting mode Function 2
Font No. (configuration) Code page
10 (9 × 17) Page 255 of Font B
12 (12 × 24) Page 255 of Font A
To Next Page
