CONFIDENTIAL
Paper roll Printing paper commands FS ( L
Ver. 10.01 p. 651
■ [Position information B] is shown in the following.
• Bits 0 and 1 always becomes “0” when the paper layout is “Receipt (without black mark)” and when
the cover is open.
• “Present label” is a print area of the label paper or the black mark paper which corresponds to either of
the following:
a) “Print area where print start position exists right under label peeling position” right after executing
<Function 65>.
b) “Print area where print start position exists right under cutting position” right after executing
<Function 66> .
c) “Print area at print start position” right after executing <Function 67> and the print start operation.
d) Print area with print position, except for the above-mentioned.
• “The next label” is “print area of the following label paper or the black mark paper of the present
label. “
■ See previous [Notes for transmission process] for description of transmission process.
[Model-dependent variations] TM-L90
Bit Function Binary Hex Decimal
0 The print start of the current label can operate. 0 00 0
The print start operation of the current label is impossible. 1 01 1
1 The print start of the next label can operate. 0 00 0
The print start of the next label is impossible. 1 02 2
2 to 5 (Reserved) - - -
6Fixed 1 4064
7Fixed 0 000
