Fire Alarm Computer 8000C / M
The full configuration of the FACP 8000M contains a basic module, the power supply module and
two extension modules, each with 3 micro module slots. In this full configuration, a total number of
slots for 7 (3 + 3 + 1) freely selectable micro module are available.
Fig. 5: Configuration options two and three-piece housing FACP 8000M
Additional devices
The panel configuration may be extended by additional In-/Output modules (esserbus
®
-
transponders). It is possible to install these transponders inside the panel housing (depending on
available space) or remote from the panel together with available mounting boxes (IP-rating 50).
onfiguration options FACP 8000M
