3025EMC Master Control Switching & Channel Branding
Page 180 Revision 3.0.3
Shift Up
Decimal Number.
Total number of keys
to scroll through.
Shift Up.
Example, if you have 250
Internal Branding media
files the number to scroll
through would be 255.
Channel Shift
Not Supported
Source Preset
Source Selection
Used with Learn Mode
to programme
PGM/PST sources.
Also used with
Upstream Destination
key type to change
inputs routed to EMC
inputs.
N/A
Preset/Program
Source
Source Selection
Change the
Preset/Program Source
selection.
Note: PGM can only be
changed if the “On-Air
Enable” key is held-down.
Preset Source
Source Selection
Change the Preset
Source.
N/A
Program Source
Source Selection
Change the Program
Source.
N/A
Emergency Select
N/A
Toggle Emergency
Enable.
N/A
Bus Route
Bus Selection
Used with “Path” key to
route either the Clean
or Aux Bus.
N/A
Path Key
CLN or AUX
Used with “Bus Route”
to select the Bus that
will be routed.
N/A
Preset Source
Overflow
Source Selection
This key will
automatically re-
purpose itself so that
the current PST Source
in
the upstream router
can always be shown
on the panel.
If this key is used it is
recommended that a
minimum of 2 of these keys
are configured.
Program Source
Overflow
Source Selection
This key will
automatically re-
purpose itself so that
the current PGM
Source in the upstream
router can always be
shown on the panel.
If this key is used it is
recommended that a
minimum of 2 of these keys
are configured.
Primary
Preset/Program
Source
Source Selection.
Change the Primary
Preset/Program Source
selection.
Note: PGM can only be
changed if the “On-Air
Enable” key is held-down.
Preset Input
Input A or Input B
Displays from which
input the Preset Bus is
taking its source from.
A is Program Input and B is
Preset Input.
Program Input
Input A or Input B
Displays from which
input the Program Bus
is taking its source
from.
A is Program Input and B is
Preset Input.
