3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 181
Preset/Program
Source Overflow
Source Selection
This key will
automatically re-
purpose itself so that
the current PGM/PST
Source in the upstream
router can
always be
shown on the panel.
Note: PGM can only be
changed if the “On-Air
Enable” key is held-down.
Main/Reserve Inputs
Not Supported
Upstream Dest (SP-1)
Source
Source Selection
These keys allow the
user to control a
destination on the
upstream router that is
not feeding an EMC
input.
Could also be used to route
the PGM Bypass Input
destination. Configured in
the “Upstream Router Tab”.
Upstream Dest (SP-2)
Source
Source Selection
These keys allow the
user to control a
destination on the
upstream router that is
not feeding an EMC
input.
Could also be used to route
the PGM Bypass Input
destination. Configured in
the “Upstream Router Tab”.
Upstream Dest (SP-3)
Source
Not Supported
Upstream Dest (SP-4)
Source
Not Supported
Emergency Source
Source Selection
Select the source that
is routed to the
Emergency Input of the
EMC.
N/A
Transition Type
Scrolling or Static
Selection
Select the transition
type for the next
transition.
N/A
Transition Speed
Scrolling or Static
Selection
Selects the transition
s
peed for the next
transition.
N/A
Transition Take
N/A
Start a transition
(tx_start).
N/A
Background Level
N/A
Configure if the PST
video/audio will
transition with the next
transition start.
N/A
Keyer Trans Enable
N/A
Configure if the Keyers
will transi
tion with the
next transition start.
Note: This does NOT apply
to the Internal Branding
Keyer (EMG).
User Transition
Select
User Transition
Selection
Select a pre-defined
user transition.
N/A
Fade to Black/Silence
N/A
Fade the PGM Bus to
black video and audio
silence
N/A
Preroll and
Transition Take
N/A
If the current source
has a pre-roll
Note: This key can be used
also start a transition for no
