3025EMC Master Control Switching & Channel Branding
Page 186 Revision 3.0.3
Dolby Encoder Level
Encoder 1 to 8
Toggle the level state of
the specified Dolby E
Encoder (transitional on
or off air).
N/A
Dolby Encoder On
Encoder 1 to 8
Toggle the on-air state of
the specified Dolby E
Encoder,
N/A
Dolby Encoder Auto
Detect
Encoder 1 to 4 (PGM
or PST)
This will toggle if the
auto-detect logic for the
specified Dolby E
Encoder is enabled or
disabled.
Note: The logic settings
are configured in the
“Audio Processing” tab
of EMC-Setup.
Extended Audio OnAir
Not Supported
Extended Audio Level
Not Supported
Audio Ratio Up
Not Supported
Audio Ratio Down
Not Supported
Extended Audio Ratio
Up
Not Supported
Extended Audio Ratio
Down
Not Supported
Audio Gain Up
Selection or Currently
Selected (usin
g “Audio
Input” key type).
Adjust the audio gain
level up.
If this button is
configured directly above
a rotary dial then this
button configures the
function of this dial as
audio gain up/down.
Audio Gain Down
Selection or Currently
Selected (using “Audio
Input” key type).
Adjust the audio gain
level down.
If this button is
configured directly above
a rotary dial then this
button configures the
function of this dial as
audio gain up/down.
Audio Input Format
Not Supported
Audio Input
N/A (scrolling)
Scroll through the audio
inputs so that
adjustments can be
made accordingly.
N/A
Duration Up
N/A
Adjust the length of the
transition (frames) up.
Note: This will adjust and
be saved to the currently
selected transition speed
ONLY.
Duration Down
N/A
Adjust the length of the
transition (frames) down.
Note: This will adjust and
be saved to the currently
selected transition speed
ONLY.
Dwell Time Up
N/A
Adjust the transition
dwell time (frames) up.
Note: Dwell only applies
to some transition types.
Dwell Time Down
N/A
Adjust the transition
dwell time (frames)
down.
Note: Dwell only applies
to some transition types.
