evertz 3025EMC - Page 199

3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 185
MG Control Keys 2
MG Logo Gain Up
Adjust current media
gain level up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as media gain up/down
or layer up/down.
MG Logo Gain Down
Adjust current media
gain level down.
MG Layer Up
Adjust current media
layer up.
MG Layer Down
Adjust current media
layer down.
MG MSK Control
N/A (scrolling)
NO TRAN
Media will NOT change
state with a transition.
CUE→PGM
Any cue’d media will
fade-
in with the next
transition.
PGM→CUE
Any on-air media will
fade-out back to a cue’d
state with the next
transition.
PGM→CAC
Any on-air media will
fade-
out back to a
cached state with the
next transition.
Audio Level
Not currently supported
Always AFV (Audio
Follow Video).
Voiceover1OnAir
N/A
Toggles the on-air state
of VO1.
N/A
Voiceover2OnAir
N/A
Toggles the on-air state
of VO2.
N/A
Voiceover3OnAir
(EMC)
N/A
Toggles the on-air state
of VO3.
N/A
Voiceover4OnAir
(EMC)
N/A
Toggles the on-air state
of VO4.
Note: If VO4 is assigned
to audio clips then this
will take VO4 off-air
ONLY.
Voiceover5OnAir
(EMC)
N/A
Toggles the on-air state
of VO5.
N/A
Voiceover1Level
N/A
Toggles the level state
of VO1 (transitional on
or off air).
N/A
Voiceover2Level
N/A
Toggles the level state
of VO2 (transitional on
or off air).
N/A
Voiceover3Level
(EMC)
N/A
Toggles the level state
of VO3 (tra
nsitional on
or off air).
N/A
Voiceover4Level
(EMC)
N/A
Toggles the level state
of VO4 (transitional on
or off air).
Note: If VO4 is assigned
to audio clips then this
will only remove cue’d.
Voiceover5Level
(EMC)
N/A
Toggles the level state
of VO5 (trans
itional on
or off air).
N/A
