7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-25
4.10.2. Setting the Transition Rate
TRANSITION
Transition Rate
Rate: 1 to 600
This menu item is used to set duration (time) of the transition. The duration
is measured in frames.
Use the Ï or Ð buttons to change the Transition Rate value and press the
SELECT button.
4.10.3. Setting the Transition Swap Mode
TRANSITION
Transition Swap
Swap: Swap
Swap: No Swap
When set to Swap the input video and audio of the Preview Bus and the
Program Bus will be swapped at the end of the transition. Logos and other
media being keyed on the respective buses will also be swapped with the
inputs.
When set to No Swap the input video and audio of the Preview Bus will be
transferred to the Program Bus transition. Logos and other media being
keyed on the Preview Bus will also be transferred to the Program Bus. The
Preview Bus will remain unchanged.
4.10.4. Pausing a Transition
TRANSITION
Transition Pause
Pause: On
Pause: Off
This menu item is used to set whether the Transition can be paused.
When set to On, the transition may be paused by pressing the TAKE
button while the transition is being performed. To continue the transition,
press the TAKE button again.
When set to Off, the transition cannot be paused.
4.10.5. Setting Program Bus Change
TRANSITION
Program Bus Change
Switch: Clean
Switch: Hard
This menu describes the action when the user makes a “Hot cut” on the
program bus. For instance, rather than selecting the next source on the
Preset bus and then executing a transition, the next source will out directly
onto the Program bus.
When set to Clean, the audio and video transition will be a clean, smooth
action.
When set to Hard, the audio and video transition will be a hard, abrupt
action.
