7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-40 Revision 1.4 RCP OPERATION
MEDIA
Crawl BG
R:255G:B 0 G: 0
This menu item is used to set the background colour for the crawl logo.
When you first enter this menu item you will be shown a set of colour
values for each of the RGB colour components. The display will be similar
to the following:
R:255G:B 0 G: 0
To change the colour value, press the SELECT button. The colon (:) after
the R will change to an equals (=) sign indicating that you can change the
R value. Use the Ï or Ð buttons to change the red colour component
value. When you press the SELECT button the colon after the G will
change to an equals sign indicating that you can change the G value.
Proceed to set the G and B values in the same way. After changing the B
value, press the SELECT button and the display will be similar to the
following:
R:255G:B 128 G: 128
This indicates that the background colour value has been changed.
4.14.9. Audio Clip Configuration Items
The 7725DSK-LG has the ability to insert audio clips into the program audio path.
Please note that the 7725DSK-LG does not currently support playlists, and therefore the audio clips
can only be played by themselves.
The Media Setup menu has a few items that are used to configure audio clips, and these items are only
available when you select an audio clip.
4.14.9.1. Setting the Audio Clip Repeat Count
MEDIA
CL Repeat:
CL Repeat:0
CL Repeat:1 to 100
This menu item is used to set the number of times the audio clip will play.
If you set the Repeat control to 0 the audio clip will play continuously.
4.14.9.2. Audio Clip Configuration
MEDIA
CL config:
CL config: HTML
This menu points the user to configure the audio clip in the HTML Setup
page.
