7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
UPGRADING FIRMWARE Revision 1.4 Page 8-3
3. To upgrade the firmware, the user must select the Upgrade… button at the bottom of the drop
down menu.
4. An upgrade window will appear. The user will then select the location of the BIN file required for the
firmware upgrade. The bin file required will be “hd7725dsklg_xxxx.bin” for running HD and
“sd7725dsklg_xxxx.bin” for running SD.
5. Click the “Open” button to start the firmware upgrade. In the console menu of Overture it will
indicate the status of the firmware file being uploaded. When the upgrade process finishes, the unit
will re-boot automatically.
6. Since the upgrade was performed using Overture Suite 2, the 7725DSK-LG will reboot
automatically.
8.3. FIRMWARE UPGRADE VIA TERMINAL PROGRAM
Upgrading the firmware using the terminal program is a two step process.
8.3.1. Step 1: Transferring the File to the CF
The user must transfer a file called "firmware_7725DSKLG" onto the Compact Flash (CF). The user
can transfer this file in one of two ways.
8.3.1.1. Method 1: Using Overture 2
The user can transfer the “firmware_7725DSKLG" file using Overture 2.
1. Navigate to the Compact Flash on the selected device to display the items located on the CF.
2. Navigate to the appropriate folder in the Media pane which contains the
"firmware_7725DSKLG" file.
3. To transfer the file to the compact flash, highlight the file from the Media pane and drag it into
the Remote Media window.
"
Note: When “firmware_7725DSKLG” file is transferred it will not be visible in the
Remote Media pane of Overture, this is made intentionally to prevent the file
from being deleted.
