7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-18 Revision 1.4 RCP OPERATION
4.6.10. Protecting Line 21 Captions
GENERAL
Line 21 Protect
L21 Prot: Yes
L21 Prot: No
This menu item allows the user to control logos that can be placed on line
21 where closed captions are located in North American television
systems. When the video standard is set to one of the 625 line standards,
the setting of this menu item is ignored.
When set to Yes, logos can be placed vertically beginning at line 22,
preserving any closed caption information that is encoded on line 21.
When set to No, logos can be placed vertically beginning at line 21.
This feature is available on SD Units only.
4.6.11. Setting the Unit Name
GENERAL
Unit Name
EVZx
This menu item allows the user to set the keyer unit name required when
the 7725DSK-LG keyer is used in conjunction with a M2100 control panel.
Each keyer connected to the panel must have a unique name assigned.
EVZ1 through EVZ8 are available. EVZ1 is the default.
4.6.12. Setting the Up Down Timer
GENERAL
Up Down Timer
Timer: Timer1
Timer: Timer2
This menu item selects which of the 2 timers the rest of the sub-menu
items will affect.
Timer 1 is selected by default. To select Timer 2, press the SELECT
button and use the Ð pushbutton to scroll to Timer2, then press the
SELECT button again.
GENERAL
Up Down Timer
Hour: 0
This menu item sets the hours for the timer. It can be set to values from 0
to 23 hours.
To change the value press the SELECT button then use the Ï or Ð
pushbuttons to change the hours for the timer. Pressing SELECT again
will set the value.
GENERAL
Up Down Timer
Minute: 0
This menu item sets the minutes for the timer. It can be set to values from
0 to 59 minutes.
To change the value press the SELECT button then use the Ï or Ð
pushbuttons to change the minutes for the timer. Pressing SELECT again
will set the value.
GENERAL
Up Down Timer
Second: 0
This menu item sets the seconds for the timer. It can be set to values from
0 to 59 seconds.
To change the value, press the SELECT button and then use the Ï or Ð
pushbuttons to change the seconds for the timer. Pressing SELECT again
will set the value.
