4.11.3. Recalling a User Preset
PRESET
Recall Preset
Recall # 1
This menu item is used to recall 1 of the 10 user presets to the Preview
Bus.
Use the Ï or Ð buttons to select the preset to restore. When you press
the SELECT button the preset will be restored to the Preview Bus
overwriting the active preset. These settings will show on the Program Bus
when the TAKE button is pressed, or a GPI trigger invokes the transition.
4.11.4. Storing a User Preset
PRESET
Store Preset
Store # 1
This menu item is used to store the Program Bus settings to 1 of the 10
user presets.
Use the Ï or Ð buttons to select which preset to save the settings to.
When you press the SELECT button the settings will be saved overwriting
any preset that was previously stored at that location.
4.11.5. Exporting a User Preset
PRESET
Export Preset
dump preset # 1
This menu item is used to send the settings to 1 of the 10 user presets to
the console serial port (UPGRADE 232) as ASCII text. This function is
useful in archiving the settings of the presets or for diagnostic purposes.
Use the Ï or Ð buttons to select the preset that you want to export. When
you press the SELECT button the settings will be sent as ASCII text to the
UPGRADE 232 serial port. To capture these settings you can use any
terminal program such as HyperTerminal. Connect the computer using the
instruction in section 8.3.2.1, and then use the Text capture function of your
terminal program to save the ASCII text.
4.11.6. Selecting the Source of the Preset Settings
PRESET
Preset Source
store program
store preview
This menu item is used to select the source of the preset settings.
Select store program to use the Program Bus as the source of the preset
settings.
Select store preview to use the Preview Bus as the source of the preset
settings.
