GENERAL
Up Down Timer
Direction: Down
Direction: Up
This menu item sets the direction for the Timer.
To change the direction, press the SELECT button and then use the Ï or Ð
pushbuttons to scroll through the options. Pressing SELECT button again
will set the value.
4.6.13. Automation Debug Functions
Two automation debug functions are provided in the GENERAL menu. One is for the Evertz
automation protocol and is called Automation Debug. The other is for the M2100 automation protocol
and is called M2100 Auto Debug. Both work in essentially the same way. When you turn on one of
the automation debug functions, the data packets being received from the automation system are
output to the Upgrade RS-232 serial port. To view the data, use a terminal program with the following
settings: baud rate: 57600, data bits: 8, parity: none, stop bits: 2, flow control: none.
These functions are used to view the commands that are being sent by the automation system. If you
are having problems with a unit that is being controlled from automation, Evertz service personnel may
ask you to provide a capture of the data being output on the serial port when the debug function is
turned on.
GENERAL
Automation Debug
Off
On
This menu item sets the Automation Debug ON or OFF.
The OFF command is selected by default. To set the Automation Debug,
press the SELECT button and then use the Ï or Ð pushbuttons to scroll
through the options. Pressing the SELECT button gain will set the value.
GENERAL
M2100 Auto Debug
Off
On
This menu item sets the M2100 Auto Debug ON or OFF.
The OFF command is selected by default. To set the M2100 Auto Debug,
press the SELECT button and then use the Ï or Ð pushbuttons to scroll
through the options. Pressing the SELECT button gain will set the value.
4.7. FILE MANAGEMENT CONFIGURATION ITEMS
The 7725DSK-LG comes standard with a 1GB re-moveable compact flash memory for storing logos
and other media files. The MANAGE FILES Setup menu is used to set up various items related to the
moving logo files between these different media drives. Table 4-2 shows the items available in the
MANAGE FILES Setup menu. Sections 4.7.1 to 4.7.5 provide detailed information about each of the
sub-menus.
Media
Selects the source media for the file operation
File
Selects the media file for the file operation
To
Selects the destination media for the file operation
Delete
Deletes the media File from the Source media
Format
Erases the Destination media
Table 4-2: Top Level of the Manage Files Setup Menu
