7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-35
EAS
Warning BG
R:255G:B 0 G: 0
This menu item is used to set the background colour for the warning
messages. When you first enter this menu item you will be shown a set of
colour values for each of the RGB colour components. The display will
show something like:
R:255G:B 0 G: 0
To change the colour value, press the SELECT button. The colon (:) after
the R will change to an equals (=) sign indicating that you can change the
R value. Use the Ï or Ð buttons to change the red colour component
value. When you press the SELECT button the colon after the G will
change to an equals sign indicating that you can change the G value.
Proceed to set the G and B values in the same way. After changing the B
value, press the SELECT button and the display will show a value similar
to:
R:255G:B 128 G: 128
4.14. MEDIA CONFIGURATION ITEMS
The MEDIA Setup menu controls all the parameters for individual logos and audio clips. Table 4-8
shows the items available in the MEDIA Setup menu. Sections 4.14.1 to 4.14.3 provide detailed
information about each of the sub-menus. Specific menu items apply to certain media types only.
To configure a specific logo exit the Setup menu and use the Ï or Ð buttons to select a particular
media item. If you want to see the logo as you are positioning it then press the LOGO IN/OUT key to
fade the logo in. The media key layer must be enabled for the output bus you are viewing in order for
the logo to be visible. Press the SETUP button to enter the Setup menu. Navigate to the Media menu
using the Ï or Ð buttons, then press the SELECT button to enter the Media menu. If the media key
layer is active on the program output bus and the PGM BUS LOCK LED is ON, you will not be able to
make changes to the logo settings.
