7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-27
The GPI script files are text files therefore they can be easily edited in notepad. See section 5.1.5 for
more information on GPI scripting.
4.11.1.1. Selecting One of the GPI Inputs to Configure
PRESET
GPI Setup
Configure GPI:A
GPI=A to H
This menu item is used to select one of the GPI inputs that will be
configured using the other menu items in the GPI SETUP menu branch.
When you first enter this menu branch the selected GPI input will be
shown. To change to configuring another GPI input press the SELECT
button. The display will show GPI=A indicating that the GPI input can be
changed. Use the Ï or Ð buttons to select the GPI input you wish to
configure and press the SELECT button. You can configure the preset to
load, transition to make and logo to display when the selected GPI input is
closed and opened using the other menu items in the GPI SETUP menu
branch.
4.11.1.2. Configuring the GPI Actions
There are 4 menu items that configure the actions when the selected GPI closes (CTransition, CLoad,
CAction, and CLogo). There are also 4 menu items that configure the actions when the selected GPI
opens (OTransition, OLoad, OAction, and OLogo). For the sake of clarity in the manual only, the On
Close event menu items will be shown. The applicable GPI is shown on the left of the front panel
display. Each GPI can be independently configured by first selecting the GPI using the GPI menu item
described in section 4.11.1.1.
PRESET
GPI Setup
A CTransition
A CTransition: No
A CTransition: Ye
This menu item is used to select whether a transition will occur when the
GPI is closed to ground.
If you do not want to perform a transition when the GPI is closed, select the
No item.
Select Ye (yes) to perform a transition when the GPI is closed.
PRESET
GPI Setup
A CLoad Prest:NON
NON
1 to 10
This menu item is used to select the preset that will be loaded when the
GPI input is closed to ground.
If you do not want to load a user preset when the GPI is closed, select
none item. If none is selected then the existing settings will be used.
Select 1 to 10 to load a specific user preset when the GPI is closed.
