7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-10 Revision 1.4 RCP OPERATION
4.6.1. Selecting the Video Standard
GENERAL
Select Standard
525i
16x9 525i
625i
720p/50
720p/59.94
1080i/50
1080i/59.94
The Select Standard menu item is used to set the video standard in use.
Select 525i/59.94 for operation with 4 x 3 aspect ratio 525i/59.94 video
conforming to SMPTE 125M. (SD Units)
Select 16x9 525i for operation with 16 x 9 aspect ratio 525i video
conforming to SMPTE 125M. (SD Units)
Select 625i/50 for operation with 4 x 3 aspect ratio 625i/50 video conforming
to EBU TECH 3267-E. (SD Units)
Select 720p/50 for operation with 720p/50 video conforming to SMPTE
296M. (HD units only)
Select 720p/59.94 for operation with 720p/59.94 video conforming to
SMPTE 296M. (HD units only)
Select 1080i/50 for operation with 1080i/50 video conforming to SMPTE
274M. (HD units only)
Select 1080i/59.94 for operation with 1080i/59.94 video conforming to
SMPTE 274M. (HD units only)
Please note that if the user wants to set the video standard to 525i or 625i
on an HD unit, load the latest SD 7725DSK-LG firmware onto the HD unit.
4.6.2. Setting the Video Output Timing With Respect To Reference
GENERAL
Reference Timing
Type
In Video
In Genlock
This menu item allows the user to set the reference type. The downstream
keyer can be referenced by the input video or by the source applied to the
REF IN BNC.
!
The H and V Phase Offset adjustment is a REAL TIME ADJUSTMENT and will
affect the output video timing immediately. These settings should not be
adjusted when the output video is in the broadcast chain.
