Page 4-36 Revision 1.4 RCP OPERATION
H
Sets the horizontal position of the selected logo
V
Sets the vertical position of the selected logo
Gain
Sets the opacity (inverse of transparency) for the selected logo
Fade In
Sets the fade in duration for the selected logo
Hold
Sets how long the selected logo will be displayed
Fade Out
Sets the fade out duration for the selected logo
UD Timer
Configures the up down timer for the selected logo
Rate
Sets the crawl rate for the selected crawl logo
Repeat
Sets the repeat count for the selected crawl logo
Pause
Sets the pause time between repetitions of the selected crawl logo
Font
Sets the font used to display the text on the selected crawl logo
Font Hei
Sets the font size used to display the text on the selected crawl logo
BG Opacity
Sets the background opacity for the selected crawl logo
FG Opacity
Sets the font opacity for the selected crawl logo
Crawl BG
Sets the colour of the background for the selected crawl logo
Crawl FG
Sets the font colour for the selected crawl logo
CL Repeat
Sets the repeat count for the selected audio clip
CL config
Directs the customer to configure the audio clip through the HTML
Setup page
Table 4-8: Top Level of the Media Setup Menu
4.14.1. Setting the Logo Horizontal Position
MEDIA
H
H:0
0 to max pixels
This menu item is used to set the horizontal position for the current logo.
The position is referenced to the left edge of the logo. The range of values
depends on video standard in use.
Use the Ï or Ð buttons to adjust the position. The logo will move on the
screen as you adjust its position.
