7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-17
GENERAL
COM D
None
EAS CG
Temperature
Automation
M2100_AUTO
XY_AUTO
Xenon Router
Ten XL
This menu item allows you to set the communications protocol that will be
used on COM Port D.
Select None to disable the use of COM Port D
Select EAS CG when the EAS option (+EAS) is enabled and the EAS
decoder is connected to the appropriate port.
Select Temperature when you have the optional temperature probe
connected to the port. See section 2.9 for more information about
connecting the temperature probe. The temperature is displayed using a
preformatted Temperature logo, which is created using Overture™
software. See the Overture™ manual on creating the Temperature logo.
There are three settings that are used when the 7725DSK-LG is under
automation control. See your automation vendor for information about the
protocols that are supported.
Select Automation when you want to control the 7725DSK-LG using the
Evertz automation protocol. This is the setting you should use when you
are controlling the 7725DSK-LG from the Evertz MetaCast 2 software.
Select M2100-AUTO when you want to control the 7725DSK-LG using the
Grass Valley M2100 7725DSK-LG automation protocol.
Select XY-AUTO when you want to control the 7725DSK-LG using the xy
logo inserter automation protocol. Note that only logo functions of the
7725DSK-LG can be controlled using the xy automation protocol.
Select Xenon Router when you want to control the 7725DSK-LG while using
the Xenon Router.
Select the Ten XL Control when you want to control the 7725DSK-LG using
a router. The Ten XL Control can only be selected on COM D port, which is
the router control port.
4.6.9. Setting the Genlock Status
GENERAL
Genlock Status
Ref is unlocked
Ref is locked
This menu item displays the status of the keyer in regards to genlock. The
status will indicate whether the keyer is locked to reference or not.
