7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-15
4.6.4.11. Setting the LTC Date Format
GENERAL
Time Setup
LTC Date Encode
Auto
Skotel
This menu item is used to select the format of the date encoded in the user
bits of the LTC. For Skotel time code generators, choose Skotel. For all
other time code generators choose Auto.
4.6.5. Setting Up the Network Addresses
The Network Info sub-menus of the General Setup menu are used to configure the 7725DSK-LG for
FTP uploads of logos and other media. In most cases you will only have to plug in your Ethernet cable
and configure the network IP address (A) to contain an unused IP address in the valid range. Entries
are made in standard IP address format. Please consult your Network administrator for IP address
allocations, netmask and gateway requirements.
To set the various Network Info parameters, press the SELECT button when the desired parameter is
shown on the front panel display (indicated by the letter on the left side of the display). The left group
of digits will be flashing to indicate that they are in entry mode. Use the Ï or Ð buttons to change this
group to the desired value. Then press the SELECT button and the next group of digits will be
flashing to indicate that they are in entry mode. Set the remaining groups of digits in the same way.
When you have entered the correct value for the right group of digits, press the SELECT button to set
the parameter. The display will stop flashing to indicate that the parameter value has been set.
The settings become active immediately after you return to the Network Info menu level. A reboot is
not required.
4.6.5.1. Setting Up the IP Address
GENERAL
Network Info
A 196.168.1.1
This menu item sets the unique IP address of the 7725DSK-LG within the
network. 192.168.1.XXX is an example of an IP address in a private
(internal) network. If connecting multiple 7725DSK-LGs, take care not to
use the same IP address for each.
4.6.5.2. Setting Up the Sub Net Mask
GENERAL
Network Info
M 255.255.255.0
This menu item sets the “subnet mask” of the network. Specifically, this
parameter outlines all the IP addresses that can communicate with the
7725DSK-LG. This parameter is usually set to 255.255.255.0 for a private
network.
4.6.5.3. Setting Up the Gateway
GENERAL
Network Info
G 192.168.1.1
This menu item identifies the IP address of the “gateway” (commonly
referred to as the “firewall”). In its simplest sense the gateway could be the
PC directly connected to the 7725DSK-LG and running the network
application software (i.e. Overture™). In a private network, this gateway
could be identified as 192.168.1.YYY.
