7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-34 Revision 1.4 RCP OPERATION
4.13.3. Setting the Font used for the EAS Crawl Display
EAS
Font
Font Name
This menu item is used to set the font that will be used for the EAS
scrolling text message.
When you first enter this menu branch the current font name will be shown.
If there are no true type fonts loaded then the display will show font as the
default font name. To change the font to another true type font press the
SELECT button. The display will show font=font indicating that the font
can be changed. Use the Ï or Ð buttons to select the from the available
true type fonts that have been loaded using the Overture™ software.
When you press the SELECT button the display will show
font:fontname indicating that this is the new display font.
4.13.4. Setting the Font Size for the EAS Crawl Display
EAS
Font Height
10
10 to 200
This menu item is used to set the font size that will be used for the EAS
scrolling text message.
The EAS height is the vertical size of the font measured in lines of video.
4.13.5. Setting the Crawl Rate for the EAS Crawl Display
EAS
Rate
16.0
1.0 to 60.0 seconds
This menu item is used to set the speed with which the scrolling text moves
from right to left across the screen measured in seconds.
The default is 16.0 seconds. The parameter is adjusted in 0.1 second
increments.
4.13.6. Setting the Colours for the EAS Crawl Display
There are three different levels of EAS messages – warning messages, watch messages and test
messages. Each message typically has a different background and foreground colour associated with
it so that the viewer will immediately know the severity of the EAS alert. There are six menu items used
to set the foreground and background colours. For the sake of simplicity only the menu item for setting
the warning background colour will be shown in the manual. The other menu items are used in the
same way.
