7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 5-12 Revision 1.4 HTML
5.1.5.3. Bring Up a Trouble Slide Called “trouble”
These 2 GPI scripts will fade out all displayed logos and stop all audio clips as well as invoke a full
screen logo called “trouble” or a trouble slide. The slide must first be prepared in InstaLogo™ or
Overture™ and uploaded to the unit.
GPI_H_Close – file name: gpi-h-close
# Logo commands
cmd media_all_out()
cmd media_in("trouble")
GPI_H_Open – file name: gpi-h-open
# Logo commands
cmd media_all_out()
The Logo Layer must be enabled for logos and audio clips to playout on the desired output bus of
DSK-LG. If you want to preview an audio clip, make sure the logo layer for the Preview Bus is enabled
and disable the logo layer on the Program Bus for the DSK-LG. Use Cue in the LGA units, however,
there is a known bug in that cued audio clips playout on the program output.
