7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-33
Type
Selects how the EAS Crawl will transition onto the video
Vert Pos’n
Sets the vertical position of the EAS crawl
Font
Sets the font used to display the EAS crawl
Font Height
Sets the font size used to display the EAS crawl
Rate
Sets the crawl rate of the EAS crawl
Warning BG
Sets the colour of the background for EAS warning messages
Warning FG
Sets the font colour for EAS warning messages
Watch BG
Sets the colour of the background for EAS watch messages
Watch FG
Sets the font colour for EAS watch messages
Test BG
Sets the colour of the background for EAS test messages
Test FG
Sets the font colour for EAS test messages
Table 4-7: Top Level of the EAS Setup Menu
4.13.1. Setting the EAS Display Type
EAS
Type
Ramp On
Ramp Off
This menu item is used to select how the EAS message will transition onto
the video
Select Ramp On to have the crawl background appear as the text scrolls
from right to left across the screen.
Select Ramp Off to have the crawl background appear all at once.
4.13.2. Setting the Vertical Position of EAS Crawl Display
EAS
Vert Pos’n
20
20 to 248
This menu item is used to set the vertical position of the EAS scrolling text
message. The Vert Pos’n value is the video line where the top of the
scrolling message will be placed. The range for placement is from 21 to
379 as set by the FCC rules.
When you first enter this menu branch the selected current position will be
shown. To change the vertical position press the SELECT button. The
display will show vert pos’n=21 indicating that the line number can be
changed. Use the Ï or Ð buttons to select the line number and press the
SELECT button. The display will show vert pos’n:xx indicating that
this is the new display position.
