4.14.6. Setting the Logo Fade Out Duration
MEDIA
Fade Out
Fade out: 30f
This menu item is used to set the fade out rate for the current logo. The
range of values is 1 to 600 frames. The Fade out menu item only applies to
static and crawl logos.
Use the Ï or Ð buttons to adjust the Fade Out time and then press the
SELECT button to set the Fade Out.
4.14.7. Setting the Up Down Timer
MEDIA
UD Timer
UD Timer: None
UD Timer: Timer2
UD Timer: Timer1
The UD Timer (Up Down Timer) selects 1 of the 2 timers for the selected
media.
The default for the UD Timer is None. To change the value press the
SELECT button then use the Ï or Ð pushbuttons to scroll through the
Timer options. Pressing SELECT again will set the value.
4.14.8. Crawl Logo Configuration Items (Crawl Optioned Units Only)
When the Crawl (+CLH) option is added to the 7725DSK-LG, it has the ability to key scrolling text
messages over the program video. In order to set up the crawl logo and enter the text from the crawl
logo you will need to use the Overture™ software. The crawl is rendered by Overture™ into a logo
(EVL) file and sent to the 7725DSK-LG. See the Overture™ manual for more information on preparing
crawl logos.
The Media Setup menu has several items that are used to configure crawl logos, and these items are
only available when you select a crawl logo on units fitted with the crawl option. Sections 4.14.8.1 to
4.14.8.7 provide detailed information about each of the sub-menus.
4.14.8.1. Setting the Crawl Logo Horizontal Crawl Rate
MEDIA
Rate
Rate: 6
1 to 15
This menu item is used to set the speed with which the scrolling text moves
from right to left across the screen measured in samples per field.
For example, it will take 120 fields for the text to scroll across a 720 pixel
wide standard definition image with a scroll rate of 6. This default value of
6 should provide a comfortable rate, however should you change the size
of the font, you should also adjust the scrolling speed.
4.14.8.2. Setting the Crawl Logo Repeat Count
MEDIA
Repeat
Repeat:0
0 to 30
This menu item is used to set the number of times that the text will scroll
across the screen.
If you set the Repeat control to 0 the text will scroll continuously.
