7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-32 Revision 1.4 RCP OPERATION
4.12.3. Setting the Static Temperature
Temperature
Set Temperature
Degree: 22
-600 to 600
This menu item is used to set the temperature to be displayed in
temperature type logos when the Temp Source menu item is set to
Manual.
Use the Ï or Ð pushbuttons to change the temperature value and press
the SELECT button to set your desired temperature.
4.12.4. Temperature Read Loss
Temperature
Temp Read Loss
Show: Blank
Show: Last Valid
This menu item is used to set the behaviour when the temperature source
is lost.
Selecting Blank will display nothing.
Selecting Last Valid will display the last valid temperature.
4.13. EAS CONFIGURATION ITEMS (+E OPTIONED UNITS ONLY)
When the EAS option (+E) is added to the 7725DSK-LG, it has the ability to key Emergency Alert
messages received from a DASDEC, Sage or TFT EAS Decoder over the program video and to insert
the emergency audio over the program audio. EAS alerts can be initiated through TCP/IP using the
DVS/168 protocol from a Trilithic or Dasdec device. Text (crawl) messages and audio can be relayed
and inserted into the audio and AES. With DVS/168 audio is copied as a .wav file to the unit and
played as a clip. Configure the clip settings in the audio setup, section 4.14.9, to duck the background
audio as desired. No analog audio input is required.
The EAS Setup menu is used to configure items related to the EAS option and is only available on units
fitted with the option. Table 4-7 shows the items available in the EAS Setup menu. Sections 4.13.1 to
4.13.6 provide detailed information about each of the sub-menus.
