7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
VLPRO OPERATION Revision 1.4 Page 3-31
3.13.6.4. Setting the Logo Fade In Duration
This option is used to set the fade in rate for the current logo. The range of values is 1 to 600 frames.
The Fade In option only applies to static and crawl logos.
3.13.6.5. Setting the Logo Display Time (Hold)
This option is used to set how long the current logo will be displayed. The range of values is 1 to 600
frames. The logo will automatically fade out after the Hold time has been completed. Setting the value
to manual will cause the logo to be displayed until it is manually faded out. The Hold option only
applies to static and crawl logos.
3.13.6.6. Setting the Logo Fade Out Duration
This option is used to set the fade out rate for the current logo. The range of values is 1 to 600
frames. The Fade option only applies to static and crawl logos.
3.13.6.7. Setting the Up Down Timer
The UD Timer (Up Down Timer) selects 1 of the 2 timers for the selected media. The default for the
UD Timer is NONE.
"
Note: The Up Down Timer is only used for time objects.
3.13.7. Crawl Logo Configuration Settings
When the Crawl (+CLH) option is added to the 7725DSK-LG, it has the ability to key scrolling text
messages over the program video. In order to set up the crawl logo and enter the text from the crawl
logo you will need to use the Overture™ software. The crawl is rendered by Overture™ into a logo
(EVL) file and sent to the 7725DSK-LG. See the Overture™ manual for more information on preparing
crawl logos.
The Media tab has several items that are used to configure crawl logos, and these items are only
available when you select a crawl logo on units fitted with the crawl option. Sections 3.13.7.8 to
3.13.8.1 provide detailed information about each of the settings.
Click on a logo in the media list and the media control menu will appear at the bottom of the view.
