7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-14 Revision 1.4 RCP OPERATION
4.6.4.7. Synchronizing the Real Time Clock to the UTC Time
GENERAL
Time Setup
Jam RTC from UTC
SELECT=Confirm
The hardware real time clock (RTC) will drift slightly from the video rate
UTC Clock time under normal operation. When this drift exceeds 5
seconds the RTC will be automatically resynchronized to the UTC time.
This menu item allows the user to synchronize the RTC to the UTC Clock
time immediately.
To synchronize the RTC time immediately, press the SELECT button when
RTC force jam is shown on the display. The front panel display will
show RTC JAMMED for 1 second after the time has been synchronized.
4.6.4.8. Displaying the Local Date
GENERAL
Time Setup
LDate 00:12:30
This menu item is used to display the local date which is the UTC date
adjusted by the time zone in yy:mm:dd format.
4.6.4.9. Displaying the UTC Date
GENERAL
Time Setup
UDate 00:12:30
This menu item is used to display the UTC date in yy:mm:dd format.
4.6.4.10. Setting the Real Time Date
GENERAL
Time Setup
RDate 00:12:30
This menu item is used to display and set the real time date in the keyer
When you press the SELECT button, the display shows the current real
time date in yy:mm:dd format.
To set the date press the SELECT button and the year digits will begin
flashing to indicate that they are in entry mode. Use the Ï or Ð
pushbuttons to change the year to the desired value. Then press the
SELECT button and the month digits will begin flashing to indicate that they
are in entry mode. Set the month and day in the same way. When you
have entered the correct date press the SELECT button to update the real
time date. When you set the real time date, the UTC date will automatically
be adjusted.
"
When there is a valid LTC input to the keyer with the date encoded in the userbits,
the LTC date will overwrite the Real Time date that has been entered.
