7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
RCP OPERATION Revision 1.4 Page 4-39
4.14.8.3. Setting the Crawl Logo Pause Time between Repeats
MEDIA
Pause
Pause:0
0 to 30
This menu item is used to set the length of time (in seconds) before a new
crawl begins. The pause time is measured between the time that the text
disappears on the left side of the screen until it appears back on the right
side of the screen.
4.14.8.4. Setting the Crawl Logo Text Font Size
MEDIA
Font Hei
Font Hei: 30
5 to 100
This menu item is used to set the font size that will be used for the crawl
logo scrolling text message.
The Crawl Height is the vertical size of the font measured in lines of video.
4.14.8.5. Setting the Crawl Logo Text Font
MEDIA
Font
Font: font
Font=font
This menu item is used to set the font that will be used for the crawl logo
scrolling text message.
When you first enter this menu branch the current font name will be shown.
If there are no true type fonts loaded then the display will show font as the
default font name. To change the font to another true type font, press the
SELECT button. The display will show font=font indicating that the font
can be changed. Use the Ï or Ð buttons to select from the available true
type fonts that have been loaded using the Overture™ software. When
you press the SELECT button the display will show font:fontname,
indicating that this is the new the display font.
4.14.8.6. Setting the Crawl Logo Transparency
There are two menu items used to set the text (foreground) and background opacity (inverse of
transparency) of the crawl logo. For the sake of simplicity, only the menu item for setting the
background opacity will be shown in the manual. The other menu item is used in the same way.
MEDIA
BG Opacity
Bg Opacity:0-255
This menu item is used to set the background opacity (the inverse of
transparency) for the crawl logo.
Setting the opacity to 255 makes the background completely opaque.
Setting the opacity to 0 makes the background completely transparent.
4.14.8.7. Setting the Crawl Logo Colours
There are two menu items used to set the text (foreground) and background colours of the crawl logo.
For the sake of simplicity, only the menu item for setting the background colour will be described in the
manual. The other menu item is used in the same way.
