7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 4-28 Revision 1.4 RCP OPERATION
PRESET
GPI Setup
A CAction
A CAction: NONE
A CAction: CUE
A CAction: IN
A CAction: OUT
A CAction: TOGGLE
A CAction:DUCK IN
A CAction:DUCK O
A CAction: DUCK
A CAction: ALL OU
A CAction: TIMER1
A CAction: TIMER2
This menu item is used to select the action that will occur when the GPI
input is closed to ground.
Select None to not perform any action.
Select Cue to load the logo selected by the CLogo menu item into memory.
The logo will not be displayed by this action.
Select In to load the logo selected by the CLogo menu item into memory
and fade it in.
Select Out to fade out the logo selected by the CLogo menu item.
Select Toggle when the GPI is closed.
Select DUCK IN to begin a ‘Duck Audio Insert’.
Select DUCK OUT to end a ‘Duck Audio Insert’.
Select DUCK to toggle the state of the 'Duck Audio Insert'. If a 'Duck Audio
Insert' is in effect it will be stopped or if a 'Duck Audio Insert' is not in effect
it will be started. This function is useful if you want to use a momentary
contact closure as opposed to a maintained contact closure to trigger a
voice-over, but the disadvantage is that the current state of the voice-over
is not guaranteed.
Select All Out to fade out all logos.
Select TIMER1 or TIMER2 to initiate a count up or count down function for
a time logo.
PRESET
GPI Setup
A CLogo: (none)
None
List of logos
This menu item is used to select a logo to be acted on if the CAction menu
item is set to Cue, In or Out
Select None to disable any logo actions.
Use the Ï or Ð buttons to select from the list of available logos and press
the SELECT button to make this the active logo for the CAction menu item.
