54200/54100 Users Manual Manual Supplement
3
NEW REMOTE CONTROL COMMANDS.
The following remote control commands have been added in relation with the new functions (See also the
pages 6-25 .. 6-27 of the Users Manual):
Pattern Long form Short form
SINX/X PATTERN SINX_X PAT S
White 10% PATTERN WH_10 PAT WH_10
White 100% PATTERN WH_100 PAT WH_100
Optional 1 PATTERN OPT_1 PAT OPT_1
Optional 2 PATTERN OPT_2 PAT OPT_2
Optional 3 PATTERN OPT_3 PAT OPT_3
Optional 4 PATTERN OPT_4 PAT OPT_4
Off PATTERN OFF PAT OF (PAT O not possible!).
Note: the Remote Control Interface ignores characters that follow on to a valid command. This means that
e.g. WH_101 is interpreted as WH_10 and WH_100XYZ is seen as WH_100. On the other hand WH_99
results in an error message.
GREYSCALE.
The greyscale pattern consists of 11 vertical bars of increasing brightness on the TV screen, as per the
specification of the pattern in section 7 (page 7-9) which says the pattern contains 10 intensity steps.
In earlier versions of the generator, 10 vertical bars were displayed on the TV-screen, using only 9
intensity steps.
As a result, the pattern description and figures throughout chapter 4 are not correct. The TV screen will
show 11 vertical bars of increasing intensity instead.
CLOSED CAPTION DATA EXTENDED WITH V-CHIP DATA.
Closed Caption (CC) is extended with a limited number of Data Packets according “EIA-608 - line 21
Extended Data Services packets”, a system also referred to as ‘the V-chip system’.
For this purpose, existing Closed Caption Numbers or ‘pages’ have been extended with fixed EDS data.
The data packets represent ‘MPAA Ratings’ and ‘TV Parental Guideline’ information in the table below.
This data can be used to perform a basic test of the V-chip decoder in a TV-set.
See the pages 5-32 through 5-38 for further details on the CC system and the data transmitted.
If CC-Sequence is selected, and the generator generates the individual CC-numbers sequencially, all
EDS data sets will also sequentially be activated.
Extended Data Packets for the V-Chip system have been added to the following data sets:
Set Hex EDS data
1 (non)
2 (non)
3 01 05 41 40 0F 6A MPAA rating 'G'
4 01 05 46 40 0F 65 MPAA rating 'X'
5 (non)
6 (non)
7 01 05 48 41 0F 62 TV-Parental Guide rating 'TV-Y'
8 01 05 48 66 0F 3D TV-Parental Guide rating 'TV-MA' + violence
Start
Content Advisory (‘V-chip’)
End
Checksum
EDS-data as contained in the Closed Caption Numbers.
To Next Page
