990DSL
Users Guide
4-52
• DID PBX Emulation Test*
• DID CO Emulation Test*
• DOD PBX Emulation Test*
• DOD CO Emulation Test*
To access these tests, select
Dial-up Tests in the POTS Toolbox, then press
L. The Dial-Up Test Toolbox is shown in Figure 4-30. The optional DID /
DOD tests are shown as “grayed out” and inactive unless the feature package
has been installed in the CopperPro tester.
Setting Up a Dial-Up Test
To set up a Dial-Up test, do the following:
1. Enter the setup parameters for all associated subtests shown in Table 4-13:
Table 4-13. Dial-Up Tests and Associated Subtests
Dial-Up Test Associated Subtests
Milliwatt VF Loss
(C.O. Tone sending device)
VF Loss test
Quiet Term. VF Noise
(C.O. Quiet Termination)
VF Noise test
VF Long. Balance
(C.O. Quiet Termination)
VF Long. Balance test
Number ANI
(C.O. Smart-Pro / ANAC device)
None
On-Hook Caller ID
(Test line with Caller ID feature)
None
Call Waiting Caller ID
(Test line with Caller ID feature)
None
