Saving Test Results
Viewing Stored Test Results
7
7-7
In Figure 7-2, you can select the following options:
• View all results
• View results for a particular Wire Center
• View results for a certain time period
• Erase all results.
These options are described in the following sections.
Viewing All Results
To view all stored text results, do the following:
1. On the
Saved Results screen (Figure 7-2), press A(View All Results).
A screen similar to that shown in Figure 7-3 is displayed. The tester lists
all of the text-based results that are stored in memory, beginning with the
oldest files (those with the earliest time stamp):
More
Start
End
Upload
Saved Results
1005 Riverside Box / Cable 101 / Pair 1001:
12/15/2000, 03:15 PM
Voltage
:
TR : 0.0 VDC, 0.0 VAC
TG : 0.0 VDC,
RG : 0.0 VDC, 2.0 VAC
TR :
TG :
RG :
T
: 18,750 ft
18,880 ft
R
Bal.:
99.3%
Shorts & Grounds :
Opens
82.5 k
Ω
Ω
10.0 VAC
>100M
>100M
:
acy93s.eps
Figure 7-3. Saved Results: All Text Results
