During the test, supply the following as prompted by the DATU:
• Password (if required)
• Phone number of the line under test
• Termination code (see table below)
• Number of minutes (
Hold Time) to apply the termination.
Table 4-18 lists the terminations that the DATU can apply:
Table 4-18. DATU Manual Termination Codes
To run this test Press key(s)
Open Line 6
Short Line 7
Short & Ground Line 33
Ground Ring 37
Ground Tip 38
Hi-Level TR Tone 44
Hi-Level RG Tone 47
Hi-Level TG Tone 48
3. When prompted to hang up, press > then M.
The tester goes on-hook, and you return to the
Main menu.
4. Wait 30 seconds to allow the DATU to remove battery and apply the
termination. Then, run the appropriate tests for the selected termination.
Note
Be sure to complete all testing within the
Hold Time period, or the
tester could report erroneous measurement results.
