POTS Auto-Test
The POTS Auto-Test is a sequence of user-selectable single-ended parametric
and transmission tests. The test can be run on either spare or working POTS
pairs, with the appropriate selected tests automatically performed. It is an ideal
tool to qualify POTS pairs, as well as providing an overview for fault analysis.
Table 4-1 lists the individual tests that comprise the POTS Auto-Test. All but
the first two tests are user selectable, which gives you the flexibility to
customize an Auto-Test that fits your particular testing situation.
Setting Up a POTS Auto-Test
To set up a POTS Auto-Test, complete the following:
1. From the
Main menu, select the POTS Auto-Test.
2. Press D(
Setups).
The
Setups−POTS Auto-Test screen 1 (Figure 4-1) is displayed:
acy11s.eps
Figure 4-1. POTS Auto-Test Setup Screen 1
Two groups of setup parameters are listed on this screen. The first group
consists of the generic setup parameters, and the second group lists the
tests that you can run under the POTS Auto-Test (refer to Table 4-1).
