Fluke 990DSL - Back Panel

Controls and Connections
The CopperPro Loop Tester: at a Glance
2
2-7
Back Panel
The tester’s back panel is shown in Figure 2-2. This panel contains a speaker
(item A) and a microphone (item B). The speaker and microphone enable you
to use the CopperPro as a dial set (see “Operating the Tester as a Dial Set” in
Chapter 3 for instructions).
1
2
acy04f.eps
Figure 2-2. Back Panel
